6mm PVC Powder SRL Series Plastic Mixer Machine Heating Cooling mixed
Description
The High Speed Hot Mixer is mainly used for the mixing and coloring of polyvinyl chloride resin, the coloring and drying of polyethylene and polypropylene particles, the drying before the molding and processing of hygroscopic resins such as ABS and polycarbonate, and the mixing of phenolic resin. One of the necessary equipment for plastic processing plants, it also has a wide range of uses in rubber, pharmacy, dyes and other industries. Because Hot Mixing Machine has the advantages of fast mixing, uniform mixture, good resin absorption of plasticizers, simple machine operation, easy cleaning, strong and durable, compact structure, etc., in recent years, it has gradually replaced low-speed mixers and is widely used Production in various plastic industries.
Features
SRL-Z series plastic mixer is applicable for mixing, colouring and drying of various resin such as poly, PE,PP,PVC polypropylene, poly chloride etc.
The unit combines hot mixer and cooler mixer together .The material will get into cooler mixer for cooling automatically when they finish heating ,exhausts remaining gases and avoids agglomeration. Through setting the time or temperature, the machine can be operated automatically.
This unit is developed by importing and absorbing foreign advanced technology. By adopting PLC control, it features high automatic level, good mixing effect, complete function, compact structure and beautiful appearance. It is the ideal equipment for plastic mixing.
Two layers of sealing is adopted in the pot cover, pot cover of cooling machine adopts arch cover, which can avoic deforming,
It has features of contact construction, good performance
Packing&Shipping
1. For bulk goods, we will pack them in wooden cases
2. For full container loading, we use film packaging machine and some are packed on pallets
3. We can send it by air or sea
4. We will send photos of the goods loaded to our customers for inspection and record
5. We can deliver the goods to the customer's warehouse for loading
Main Technical Parameter
| Model | Total capacity(kg/h) | Effective capacity(kg/h) | Motor power(kw) | Spindle speed(rpm) |
| SRL-Z50/100 | 50/100 | 32/75 | 7/11/5.5 | 750/1500/180 |
| SRL-Z100/200 | 100/200 | 75/160 | 14/22/7.5 | 650/1300/150 |
| SRL-Z200/500 | 200/500 | 150/320 | 30/42/11 | 475/950/130 |
| SRL-Z300/600 | 300/600 | 200/360 | 40/55/11 | 475/950/130 |
| SRL-Z500/1000A | 500/1000 | 375/650 | 47/67/18.5 | 430/860/60 |
| SRL-Z500/1000B | 500/1000 | 350/640 | 55/75/15 | 430/860/50 |
| SRL-Z800/1600A | 800/1600 | 600/1024 | 75/30 | 500/50 |
